NEW! Baby Lock Radiance Sewing & Embroidery Machine

• StitchSync Regulation™
• 11-5/8" X 18-1/4" Embroidery Hoop
• Largest Projection Area with IQ Live Stitch™
• 14.1" to the Right of the Needle
• Precise Sewing Placement with Projected Guidelines
• Picture Play
• IQ Designer and IQ Intuition Positioning™
• Built-in Edge-to-Edge Quilting
• Voice Guidance available with some processes
• IQ Live Stitch™ Projects your embroidery design or sewing stitches in an 8" x 5" (203mm x 127mm) area
• Advance and select stitches from projection using the Dual-Purpose Stylus
• Select background color from projection using Dual Purpose Stylus
• Set stitch width, length, and left/right shift
• Projection of Guide Beam, Grid, and Needle Beam for precision alignment of stitches
• Buttonhole preview either vertically or horizontally
• NeedleCam™ Digital Camera for embroidery and sewing positioning with faster scanning
• Precise Touch Positioning™ using NeedleCam
• Camera detecting buttonhole foot with stabilization plate
• IQ Designer Scanning Frame
• Enhanced Stadium Lighting for 14.1" (358mm) area of brighter true color LED lighting on the needle and work area with 5 settings
• 2 (Type A) USB 2.0 drives
• Wireless Wi-LAN Function Directly download update files to machine
• IQ Intuition Monitoring®
• IQ Intuition Positioning®
• Design Database Transfer
• Palette 11 pattern transfer to embroidery and IQ Designer
• NeverMiss™ Automatic Advanced Threading System
• Digital Dual-Feed System
• Advanced Pivoting Feature and Automatic Fabric Sensor System
• Automatic sensors
• Embroidery and sewing speed up to 1,050 spm
• Precise tracking system on embroidery carriage
• Resume mode for Embroidery and IQ Designer
• Programmable shutoff capabilities
• Eco power mode
• Wireless mouse compatible
• 1858 Built-in embroidery designs
• 381 Baby Lock Exclusives
• • 35 Sewlebrity designs
• • 17 Buttonhole embroidery designs in 5 sizes
• • 27 Buttonhole embroidery decoration designs
• • 240 Large decorative stitch designs
• • Couching Alphabet
• • 74 Quilting designs
• • 40 Couching patterns
• • 7 Large-connect designs
• • 7 Crochet lace designs
• • 11 Large alphabet designs
• • 18 Long-stitch designs
• • 11 Applique designs
• 39 font styles
• 1610 Built-in stitches
• 184 Utility
• 15 one-step buttonhole styles and 1 four-step custom buttonhole
• 527 Decorative
• 79 Decorative satin
• 20 Satin
• 21 Cross-stitch
• 63 Combinable Utility
• 3 Hand-look Quilting
• 20 Tapering
• 4 Built-in alphabets
• 40 Quilting stitches offer 57 needle position options
• Stitch length 0.0mm - 5.0mm (Stitch length over 2mm can increase in increments of 0.2mm)
• 2 Basting stitch options: Regular (5mm) and free‑motion
• Maximum Utility stitch width 7mm
• Utility stitch editing capabilities
• 5 Memory settings for each Utility stitch
• Decorative stitch editing capabilities
• Sewing function is available while the embroidery arm is attached
• Specify end-point for stitch line with capability to end with a completed pattern
• Stitch taper for specifying start and end angles of a select category of stitches
• Dual Feed Foot
• Stitch Regulator
• Automatic drop feed key on screen
• Lock key for Utility and Decorative stitches
• Increase in bobbin capacity 4.5m (14.75 feet)
• Larger sewing bed and workspace with 14.1" (358mm) to the right of the needle
• Frosted surface finish on machine bed
• One-Touch button for Start/Stop
• One-Touch button for Reverse sewing
• One-Touch button for Reinforcement key
• One-Touch button for Needle up/down
• One-Touch button for Thread cutter
• One-Touch button for Automatic presser foot lift
• One-Touch button for Automatic needle threading
• Sewing speed control doubles as width control
• Quick-Set, Top-Loading bobbin with sensor
• Quick-Set Independent bobbin winding system
• One finger removable needle plate for easy access cleaning
• Ergonomic 3-position, adjustable knee lift with extra high presser foot lift - 10mm Automatic and 13mm Manual
• Programmable 3-step needle up/down
• Adjustable volume with 5 settings
• Automatic thread cutter (with on/off capability)
• Needle plate with scale in inches and centimeters and additional guideline markings
• Free arm
• Foldable two-spool thread stand attaches magnetically to machine lid
• Two accessory storage compartments in sewing tray
• Enhanced Accessory Storage Box with 3 interchangeable trays
• Built-in Instruction and Reference Manual
• Built-in Operational Guide with up to 40 help topics
• Videos available online using QR code
• Built-in Sewing Application Guide
• Built-in Help Messages
• Embroidery Stitch Count System – SCS
• Capability to save settings screen images

FEET

• 1/4" Quilting foot with Guide
• Blind Stitch Foot "R"
• Button Fitting Foot "M"
• Camera Detecting Buttonhole Foot with Stabilization Plate
• Couching Dual Feed sole
• Compact Digital Dual-Feed System
• Embroidery foot “W”
• Embroidery Couching Foot "Y"
• Free Motion Echo Quilting "E"
• Free Motion Open Toe Quilting Foot "O"
• Free Motion Quilting Foot "C"
• General Purpose Zig Zag Foot "J"
• Advanced Monogramming Foot "N+"
• Overcasting Foot "G"
• Stitch Regulator
• Stitch Regulator Quilting sole
• Stitch Regulator Open Toe Quilting sole
• Stitch Regulator Echo Quilting sole
• Straight Stitch Foot
• Zipper Foot "I"

ACCESSORIES

• Dual Purpose Stylus
• Adjustable knee lifter with 3-position handle
• Advanced multi-function foot controller
• Easy-lock accessory case for presser foot storage with 3 interchangeable trays
• 2 Thread king spool stand for larger cones
• Straight stitch needle plate
• Bobbin Covers with and without markings
• Alternate bobbin case
• Bobbin center pin
• Embroidery bobbin thread
• Bobbins
• Embroidery Positioning Stickers (2 Sheets)
• End-point stickers (4 sheets, 243 stickers per sheet)
• White needle calibration stickers
• Multi-position screwdriver
• Presser foot adaptor
• Seam ripper
• Scissors
• Eyelet Punch
• Spool nets (2)
• Foot control
• Twin needle
• Yarn guide for couching
• Yarn threader
• Scanning frame with magnets
• Embroidery Support Table
• Embroidery hoops 115/8" x 181/4" (297mm x 465mm)
• 105/8" x 105/8" (272mm x 272mm)
• 5" x 7" (130mm x 180mm)
• 4" x 4" (100mm x 100mm)

• 25 years casting limited
• 10 years parts
• 5 years circuit boards
• 5 years electrical
• 1 year labor

• Weight: 59lbs
• Height: 13.78"
• Width: 26.42"
• Depth:
